GENERAL INFORMATION

Model: Hyosung GT650R

Year: 2015

Category: Sport

ENGINE & TRANSMISSION

Displacement: 647.00 ccm (39.48 cubic inches)

Engine type: V2, four-stroke

Engine details: 90° V-twin

Power: 79.00 HP (57.7 kW)) @ 9250 RPM

Torque: 66.88 Nm (6.8 kgf-m or 49.3 ft.lbs) @ 7250 RPM

Compression: 11.5:1

Bore x stroke: 81.5 x 62.0 mm (3.2 x 2.4 inches)

Valves per cylinder: 4

Fuel system: Injection

Fuel control: Double Overhead Cams/Twin Cam (DOHC)

Ignition: CDI

Lubrication system: Wet sump

Cooling system: Liquid

Gearbox: 6-speed

Transmission type, final drive: Chain

Clutch: Wet, Multiplate

Driveline: Chain 525. Constant mesh

Chassis, suspension, brakes and wheels

Rake (fork angle): 25.0°

Front suspension: Upside down Telescopic (Compression, Rebound damping adjustable)

Rear suspension: Swing arm with Progressive linkage Hydraulic Mono shock absorber (Preload adjustable)

Front tyre: 120/60-ZR17

Rear tyre: 160/60-ZR17

Front brakes: Double disc. Semi Floating discs, 4 pistons calipers

Front brakes diameter: 300 mm (11.8 inches)

Rear brakes: Single disc. 2 pistons caliper

Rear brakes diameter: 230 mm (9.1 inches)

PHYSICAL MEASURES & CAPACITIES

Weight incl. oil, gas, etc: 215.0 kg (474.0 pounds)

Seat height: 831 mm (32.7 inches) If adjustable, lowest setting.

Overall height: 1,135 mm (44.7 inches)

Overall length: 2,090 mm (82.3 inches)

Ground clearance: 165 mm (6.5 inches)

Wheelbase: 1,435 mm (56.5 inches)

Fuel capacity: 17.03 litres (4.50 gallons)

OTHER SPECIFICATIONS

Starter: Electric

Instruments: Digital and analogue

Factory warranty: 2 years
