GENERAL INFORMATION

Model: Hyosung ST 7

Year: 2010

Category: Custom / cruiser

ENGINE & TRANSMISSION

Displacement: 678.20 ccm (41.38 cubic inches)

Engine type: V2, four-stroke

Compression: 11.5:1

Bore x stroke: 81.5 x 65.0 mm (3.2 x 2.6 inches)

Valves per cylinder: 4

Fuel system: Injection

Fuel control: Double Overhead Cams/Twin Cam (DOHC)

Cooling system: Liquid

Transmission type, final drive: Belt

Clutch: Wet, Multi plate

CHASSIS, SUSPENSION, BRAKES & WHEELS

Rake (fork angle): 33.0°

Trail: 142 mm (5.6 inches)

Front suspension: 41Ø Conventional telescopic fork

Rear suspension: Swing arm, Hydraulic double shock absorber (preload adjustable)

Front tyre: 120/80-16

Rear tyre: 170/80-15

Front brakes: Single disc

Front brakes diameter: 300 mm (11.8 inches)

Rear brakes: Single disc

Rear brakes diameter: 270 mm (10.6 inches)

Physical measures and capacities

Dry weight: 229.0 kg (504.9 pounds)

Weight incl. oil, gas, etc: 244.0 kg (537.9 pounds)

Seat height: 690 mm (27.2 inches) If adjustable, lowest setting.

Overall height: 1,135 mm (44.7 inches)

Overall length: 2,470 mm (97.2 inches)

Overall width: 960 mm (37.8 inches)

Ground clearance: 155 mm (6.1 inches)

Wheelbase: 1,690 mm (66.5 inches)

Fuel capacity: 17.98 litres (4.75 gallons)
